Heavy Engineering


Heavy engineering industry poses a completely different CAD / CAE challenge due to the massive scale of operation and the sizes involved. Due to the sheer size and weight constraints, the requirements on operational and construction safety are extremely stringent.

Also the nature of usage of the equipment under this category itself means that the every challenge is unique and needs a fresh approach and innovative thinking to design and address the problems. Pristine has a proven track record in this challenging sector and has been involved in projects of national and global repute.

Following is a brief summary of the services offering to this sector.

Heavy Engineering CAD Capabilities

Design of large structures as per standards and codes like ASME

Detailed development of structural design from concepts

Design of joints/fabrication process and manufacturing engineering support

Preparation of intermediate BOM for procurement

Design of jigs/fixture and special working holding devices for large fabrication

Assembly sequence animation and CBT's

Generation of General Arrangement (GA), fabrication, manufacturing drawings and BOM

Heavy Engineering CAE Capabilities

Validation of large structures as per standard code calculations

Analysis of large structures for Wind, Snow and Seismic loading conditions

Large Fluid Structural analysis

Weight reduction and optimization for structures

Weld joint analysis

Modal, Fatigue and Durability analysis

Failure mode analysis and what-if scenarios

Static, buckling, non-linear, dynamic, impact, explosive, thermal and other applicable analysis

Calculation of safety compliance of structures for codes like ASME, DIN, EN etc

Analysis for transportation loads and lifting conditions

Analysis for Vacuum and pressure conditions for vacuum and pressure vessels
